| 設備型號 Equipment Model | YG935E69L | YG935FW1214 II L | YG1138E71L | YG1138FW315 II L | YG1138EW86L |
| 給料機型號Feeder model | GZD-960x3500 | GZD-960x3500 | GZD-1100x3800 | GZD-1100x3800 | GZD-1100x3800 |
| 破碎機型號Crusher model | PE600x900 | PE-1214 II | PE750x1060 | PEW-1315 II | PEW860 |
| 主皮帶型號Main belt model | B800x8.5M | B800x8.5M | B1000x9M | B1000x9M | B1000x9M |
| 主皮帶卸料高度 Main belt discharge height | 3200 | 3200 | 3500 | 3500 | 3500 |
| 側出皮帶型號（選配）Side belt type(optional) | B450x3M | B450x3.2M | B500x3.5M | B500x3.5M | B500x3.5M |
| 側皮帶卸料高度 Side belt dischage height | 2800 | 2800 | 3100 | 3000 | 3100 |
| 發動機功率Engine power(kw) | 180 | 250 | 200 | 300 | 250 |
| 運輸長度 Transport length(mm) | 11900 | 11900 | 13300 | 13300 | 14200 |
| 運輸寬度 Transport width(mm) | 3100 | 3100 | 3100 | 3100 | 3300 |
| 運輸高度 Transport height(mm) | 3650 | 3650 | 4500 | 4500 | 5000 |
| 運愉重量 Shipping weight(t) | 43.5 | 50 | 59 | 59 | 67 |
| 作業長度 Working length(mm) | 12100 | 12100 | 13500 | 13500 | 15200 |
| 作業寬度Job width(mm) | 3100 | 3100 | 3100 | 3100 | 3300 |
| 作業高度 Working height(mm) | 4100 | 4100 | 5100 | 4800 | 5500 |
